This series CNC pipe threading lathe is mainly designed for processing internal and external pipe threads including metric, inch, module, DP and taper threads, as well as having all the common functions of normal CNC lathe such as processing the inner bore and end face of shafts and disks.
| SPECIFICATION | UNIT | QK1313 | QK1319 | QK1322 | |
|---|---|---|---|---|---|
| Capacity | Swing over bed | mm | 630/800 | 630/800 | 630/800 |
| Pipe threading range | mm | 30-126 | 50-193 | 50-220 | |
| Spindle | Spindle bore | mm | 130 | 206 | 225 |
| Motor | Main motor | kW | 11 | 11 | 11 |
Our factory adheres to the attitude of striving for perfection. With meticulous care, we painstakingly polish every single detailed component. Each part is treated as a masterpiece in the making. Whether it's a small screw or a crucial structural element, no detail is overlooked.
Technical Consultation, Customization Support, and detailed Quotation & Planning.
Efficient Production, Real-Time Updates with reports and photos, and Global Logistics handling.
Installation & Training, 365/24 Technical Support, and readily available Spare Parts.
A complete quality management system has been established, carrying out strict inspection in every link from raw material to assembly. We utilize coordinate measuring machines and laser interferometers to ensure quality meets national standards.
