Flexible Manufacturing Cell CNC Controller with Robot Interface

1 / 5

Flexible Manufacturing Cell CNC Controller with Robot Interface

Customization:	Available
Warranty:	3 Years
Logo Printing:	with Logo Printing

Send Inquiry

Product Description

Basic Information

Model NO.

998Ta

Type

CNC Controller

Axis Num

2-4 Axis

Display Screen

8.4 Inch

Accuracy

0.1um

Material

Stainless Steel / Aluminum Alloy

Interpolation

1ms Cycle

Capacity

50000 Sets/Year

Product Description

Technical Specification

Movement Control	Control axes: X, Z, Y, A axis. Pulse + direction output. Interpolation: Straight line, Arc. Max speed: 30000mm/min.
G Function	29 kinds of G codes including G00-G04, G32-G34, G70-G76, G90-G99. Supports complex arithmetic and logic operations.
Threading	Single/multi-head metric straight, tapered, and variable pitch threads. Pitch range: 0.0001mm to 500mm.
Accuracy	Reverse gap compensation; 512 points pitch error compensation; 32 sets of tool length and tip radius compensation.
Interface	8-inch LCD (800x600), Multi-language support (English/Chinese), Real-time processing trajectory graphics.

Packaging & Shipping

CNC Controller Package

CNC Lathe Package

To better ensure the safety of your goods, professional, environmentally friendly, and efficient export wooden crate packaging services will be provided.

Frequently Asked Questions

What components are included in your total CNC system?

We provide a complete plug-and-play solution including the CNC controller, spindle and axes drivers/motors, and all necessary cables and accessory kits.

What types of tool changers (ATC) do you support?

For lathes, we support electric, servo, and counting turrets. For milling, we support linear, umbrella, arm, and turret-type tool magazines.

Can I customize the software with my own branding?

Yes, we support custom boot logos and branding for our CNC controller systems.

What is the typical lead time for an order?

Standard orders are typically processed within 5–7 workdays. Customized solutions are available with negotiable lead times.

What international certifications do your products hold?

Our CNC controllers are certified with GS and CE standards to ensure high quality and safety for global markets.

How is speed controlled for the spindle?

The system uses analog voltage (0–10V) for speed control and can be equipped with either a servo spindle or a frequency converter.
