The CNC Vertical Milling Machine is a precision-engineered, computer-controlled machining center designed with a vertically oriented spindle-positioned perpendicular to the worktable-making it ideal for a wide range of milling operations on flat or irregularly shaped workpieces. Equipped with advanced CNC systems, it translates digital CAD/CAM designs into precise physical parts, enabling automated, repeatable machining with minimal human intervention.
Its robust construction, typically featuring a heavy-duty cast iron bed and reinforced column, ensures exceptional stability and vibration damping-critical for maintaining accuracy during high-speed cutting or heavy material removal. The worktable, driven by high-precision ball screws and servo motors, moves along the X (longitudinal) and Y (transverse) axes, while the spindle travels along the Z (vertical) axis, with positioning accuracy often within ±0.002 mm.
| ITEM | Unit | VMC650 | VMC855 | VMC1160 | VMC1370 |
|---|---|---|---|---|---|
| Worktable size | mm | 800×500 | 1000×550 | 1200×600 | 1400×700 |
| Max. Capacity Weight | kg | 400 | 500 | 800 | 1200 |
| X/Y/Z Travel | mm | 600/500/500 | 800/550/550 | 1100/600/600 | 1300/700/700 |
| Spindle Speed | r/min | 8000 | 8000/12000 | 8000 | 8000 |
| Main Motor Power | kW | 5.5 | 7.5/11 | 11/15 | 15-18.5 |
For a seamless experience, our shipping fee and delivery dates are tailored to your needs and can be easily negotiated. Reach out and chat with our supplier now for further details and personalized service.
After-sales service is the backbone of your machine's long-term performance. We offer 24/7 rapid response to any operational issues with engineers ready to troubleshoot remotely within 1 hour or arrive on-site within 24 hours for urgent needs. We stock over 10,000 genuine parts, ensuring replacements ship within 48 hours to keep your machine running at peak condition.
